Kraloy 45° Special Radius Elbows are manufactured from high impact, nonconducting and noncorroding rigid PVC. Elbows are suitable for exposed, concrete encased and direct burial applications, are lightweight and offer excellent chemical resistance with high tensile and impact strength.

FEATURES

  • Made from impact resistant Schedule 40 rigid nonmetallic PVC
  • Feature a plain end for use with nonmetallic solvent weld fittings
  • Approved for use in exposed, concrete encased and direct burial applications

Resources

PRODUCT CODE DRAWING PART NUMBER UPC SIZE RADIUS QUANTITIES
068867click to downloadEE4545-366224546886743"36R1 EA
0688636224546886361 1/4"36R1 EA
0688646224546886431 1/2"36R1 EA
068872click to downloadEE6545-366224546887286"36R1 EA
068862click to download6224546886291"36R1 EA
0688686224546886813 1/2"36R1 EA
068866click to download6224546886672 1/2"36R1 EA
068865click to downloadEE3545-366224546886502"36R1 EA
068869click to downloadEE5545-366224546886984"36R1 EA
068871click to downloadEE6045-366224546887115"36R1 EA
